2V 190cc

2V 190cc 300cfm Cleveland - SB Ford Alloy Heads

Product ID: CHI 2V 190cc Bare

	Price - 1 Pair (AUD) Price - 1 Pair (USD)	$1999   $1799
	Payment Terms

Description:

CHI is proud to announce the all new Street Master 2V cylinder head. Designed to work with standard 2V intake and exhaust manifolding the 2V Street Master cylinder heads have no equal.

At just 190cc in port volume the all new 2V flows a massive 307cfm at just .650"lift, with 300cfm at .600lift (figures taken from as cast head with a 2.100" valve), taking the 2V head to a new level of performance, never before available from a standard intake port location and size.

Features:

1. Standard Intake port locations will fit ALL 2V factory style intake manifolds GUARANTEED and our UNI exhaust port allows the use of either 2V or 4V factory exhaust manifolds.

2. 300cfm of airflow at just .600" lift.

3. 3V combustion chamber provides the most efficient burn characteristics and detonation control on the market today.

4. All new 220+cfm "UNI" Exhaust Port will fit either 2V or 4V headers with NO port matching, and features true Standard Height Exhaust Port & bolt locations.

5. 5/8" Thick Deck for positive head gasket retention and ideal for all nitrous and blown applications.

6. Standard head bolt lengths.

7. Fully CNC machined in house.

Flowchart:

Click here to enlarge

4V CNC Chambers

Product ID: 4V CNC Chambers

	Price - 1 Pair (AUD) Price - 1 Pair (USD)	$190   $171
	Payment Terms

Description:

Owners of raised dome, high compression pistons to suit 4V closed chamber heads, can now order CHI heads with a 4V CNC chamber. Our 4V CNC chambers are 74cc in volume and retain our relocated spark plug location. These can also be ordered as an option by people that require increased chamber volumes for blown or stroker applications. The need to replace those high compression 4V pistons is now a thing of the past.

3V CNC Chambers

Product ID: 3V CNC Chambers

	Price - 1 Pair (AUD) Price - 1 Pair (USD)	$190   $171
	Payment Terms

Description:

Although we CNC all our chambers as part of our manufacturing process, the step over we use is.030". This allows us to economically add this process to all our cylinder heads without adding any further expense.

For customers that want the ultimate in CNC finish we also offer a .020" super fine step over CNC chamber option. The CNC program like our standard program, gives our standard deck height heads, a chamber volume of approximately 68-70cc (depending on valve choice), with a much smoother finish.

Also available are small chamber options where we "lift" the chamber in the cylinder head so you don't have to mill down the deck face. This option will add a further $100USD and or $150 AUD to the cost of the fine step-over program. Please call or email to discuss this option further, as there are many chamber volumes we can accommodate.

STD Factory Pedestals

Product ID: STD Factory Pedestals

	Price - 1 Pair (AUD) Price - 1 Pair (USD)	$190   $171
	Payment Terms

Description:

Finally owners of standard Cleveland rocker gear and / or aftermarket bolt on standard pedestal type Cleveland roller rockers; can now order CHI heads with factory style rocker pedestals. This makes CHI heads even more affordable then ever. No longer do you need to buy roller rockers or convert to screw in studs and guide plates with alloy heads.

Our STD pedestal mounts come fitted with 5/16UNC helicoils, for the ultimate in strength and fatigue resistance. Best of all CHI will custom machine your new cylinder heads to suit standard pedestals at no extra charge.

CHI 2v 190cc Street Assembly 805-DO

Product ID: CHI 2V S/A 805-DO

	Price - 1 Pair (AUD) Price - 1 Pair (USD)	$2750   $2475
	Payment Terms
	All assembled cylinder heads packages come with free CNC chambers. (valued AU$190/US$150) * does not apply to cylinder heads with standard factory pedestals.

Description:

This complete Street cylinder head package comes with Ferrea 5000 series, stainless steel valves with hard chromed stems. We use Isky Chrome-Molly-7 Degree Retainers, Isky Machined Valve Locks (not the cheaper stamped steel versions), and Isky 805-DO valve springs.

This package is ideal for hydraulic camshafts to 230@.050 with.570"lift, or small solids up to 230@.050and .570"lift that are street driven regularly. Heads are finished of with matching Isky hardened spring pad locators to positively locate the valve spring and Viton valve stem seals for unsurpassed oil control.

CHI 2V 190cc Street Assembly 8005A

Product ID: CHI 2V S/A 8005A

	Price - 1 Pair (AUD) Price - 1 Pair (USD)	$2800   $2520
	Payment Terms
	All assembled cylinder heads packages come with free CNC chambers. (valued AU$190/US$150) * does not apply to cylinder heads with standard factory pedestals.

Description:

This complete Street cylinder head package comes with Ferrea 5000 series stainless steel valves with hard chromed stems. We use Isky Chrome-Molly-7 Degree Retainers, Isky Machined Valve Locks (not the cheaper stamped steel versions), and Isky 8005A Triple Competition valve springs.

This package is ideal for large solid cams of up to .625" lift (be sure to subtract valve lash from your camshaft specs when determining net valve lift), and is ideal for the serious street car that is raced on the odd occasion. Heads are finished of with matching Isky hardened spring pad locators to positively locate the valve spring and Viton valve stem seals for unsurpassed oil control.

CHI 2V 190cc Competition Assembly 8005A

Product ID: CHI 2V C/A 8005A

	Price - 1 Pair (AUD) Price - 1 Pair (USD)	$3000   $2700
	Payment Terms
	All assembled cylinder heads packages come with free CNC chambers. (valued AU$190/US$150) * does not apply to cylinder heads with standard factory pedestals.

Description:

This complete Competition cylinder head package comes with Ferrea 6000 series swirl polished stainless steel valves with hard chromed stems. We use Isky Chrome-Molly-7 Degree Retainers, Isky Machined Valve Locks (not the cheaper stamped steel versions), and Isky 8005A Triple Competition valve springs.

This package is ideal for large solid cams of up to .625" lift (be sure to subtract valve lash from your camshaft specs when determining net valve lift), that are raced on a regular basis. Heads are finished of with matching Isky hardened spring pad locators to positively locate the valve spring and Viton valve stem seals for unsurpassed oil control.
